Finally, a Bowden Tubing made truly custom made for 3mm filament.
3mm filament can bind in a standard PTFE tube, which is why quality '3mm' filament is normally produced to 2.85mm.
This Capricorn tubing will solve that problem.
It has the same nominal 6.35mm OD so it will work with all existing bowden systems, but it is more lubricious, more flexible, and best of all has a slightly larger ID of 3.2mm. This will permit you to run a wider range of filaments with less sensitivity to filament quality.
Give it a try Today.
Here is some more info from the manufacturer:
PTFE, or Polytetrafluoroethylene, is a synthetic polymer commonly used as a coating for non-stick pots and pans. It is the slipperiest substance known to man, and is said to be the only surface to which a gecko cannot stick. Although Bowden tubes can be made from several different polymers, PTFE is generally considered the best because of its high melting point and low coefficient of friction.
Capricorn tubing is manufactured using the most sophisticated equipment currently available. It always comes out perfectly round, and the diameter stays as consistent as possible.
Capricorn XS Bowden Tubing is made from the highest quality pure virgin Japanese PTFE, and formed using the paste extrusion process. However, we have added a "Secret Sauce" which lowers the coefficient of friction. This additive also makes the tubing opaque.
Important Note regarding interpretation of these specifications
Generally it is not safe to bring any PTFE above 260. The somewhat arbitrary melting temperature listed in this table is an indicator of stability of the material and is not indicative of a safe use temperature.
|Opaque White PTFE||Translucent White PTFE||TL Series Light Blue||XS Series Dark Blue|
|Additives||None||None||Blue Color||Blue Color and Secret High Performance Additive Mixture|
|Best For Chunky Filaments||No||No||Yes||Maybe|
|Best For Flexible Filaments||No||No||No||Yes|
|Can See Through||No||Yes||Yes||No|
|Color||White||White, Translucent||Blue, Translucent||Dark Blue|
|Density (kg/m3)||2100-2200||2100-2200||2100 +/-100||2300 +/-100|
|Linear Thermal Expansion at 250 °C||3.4-3.6%||3.4-3.6%||3.4-3.6%||2.2-3.3%|
|Material||Cheapest PTFE||Better PTFE||Highest Quality Pure Virgin PTFE||Highest Quality Pure Virgin PTFE|
|Melting Point (°C)♥||as low as 220||around 260-327||around 340||around 340|
|Outer Diameter||about 4 mm||about 4 mm||4.075 +/- 0.025||3.995 +/-0.025|
|Roundness (ϵ)||Variable||Variable||< 0.1||< 0.1|
|Thermal Conductivity (W/m-k)||0.25||0.25||0.25||0.25|
|Wear Rate (gm/s)||0.01||0.01||0.01||0.01|
|Young's Modulus (GPa)||<0.50||<0.50||0.50||0.532|
|♠Pulling Friction is calculated as the average force required to pull 1.2 meters of 1.75mm PLA filament through 1 meter of tubing at a constant speed, relative to 1 meter of cheap white reference tubing. Note that although we observed the friction of the TL series to be about the same or even slightly lower than our XS series, it also has a larger internal diameter.|
|♥PTFE does not transition quickly from a solid to liquid, but acts as a glass, slowly softening. Temperatures were approximated by heating samples of all tubing simultaneously, observing how quickly each one began to deform.|
Full specsheet: Here.View full product details
$ 14.95 $ 9.99
M6 thread, suitable for use with the Prusa i3 and i3 MK2, and the Olssen block for Ultimaker.
|Nozzle Size||Application||ID Dots*|
|0.25mm||Highest Precision - Slower Prints||0|
|0.35mm||Slight Increase in Precision||2|
|0.40mm||Balanced Nozzle - Supplied by Default||3|
|0.60mm||Our Preferred Minimum for Wood Filled Filament||4|
|0.80mm||Lower Precision - High Speed, Higher Strength||5|
* Dots are machined onto the hex-flats of the nozzles for easy identification.
View full product details
There are a couple of major flaws with groovemounting (or previous standard HotEnd mounting style):
Fit is highly dependent on quality of part machining
Fit can become loose from repeated removal and refitting
To fight these problems, we're beta-releasing a new, blue, screw-threaded heat sink. Threading also brings some benefits of its own:
It's reliable and repeatable to machine
Wear due to repeated removal and refitting is not an issue
It offers more versatile mounting options, e.g. through a threaded plate
It offers the exact same thermal performance as a standard V6 heatsink and is already in use by companies like Duet3D. We'd like you to try it next, and if you have any feedback then get in contact!
Ships with M12 nut, thermal paste and collet with clip.View full product details
Converting your Makerbot or other MightyBoard based printer over to use E3D? This is what you will need for temperature sensing.
While most 3D Printers use a thermistor which changes resistance with temperature, some printers use a thermocouple which actually generates a voltage and the magnitude of the voltage changes with temperature.
This thermocouple cartridge is compatible with all E3D components, so it is perfect for converting your beloved old Replicator or Replicator 2 over to a more modern hot end system.View full product details
